Maximum working height 2105mm
Maximum loading height 1865 mm
Maximum unloading height 1390 mm
Maximum dumping distance 600mm
Maximum unloading angle 40 °
Total height 1415 mm
Ground clearance 125 mm
Total length without bucket 1685 mm
Total width 1025mm
Bucket width 1150mm
Total length with bucket 2340mm
Folding pedal without bucket, total length 1685mm
Accessory flow rate 0-40L
Workload 300 Kg
Bucket capacity 0.15m ³
Maximum lifting capacity 380 Kg
Driving speed 0-4.5Km/h
Working weight 890 Kg
Hydraulic tank 35L
